Shapemeter roll with hard-chromium plated surface

Shape:tronic system

The ANDRITZ shape:tronic system meets the highest quality standards – our continuous fine-tuning guarantees it.

ANDRITZ Metals Germany is an experienced rolling mill manufacturer and has been building shape measurement and shape control systems under license from the VDEh-Betriebsforschungsinstitut (BFI) for more than 45 years, registered under the shape:tronic system trademark. The general-purpose shape control systems are used in various kinds of rolling mills in the steel, stainless steel, aluminum, and non-ferrous metal industries.

The ANDRITZ BFI shapemeter roll has a completely uniform, homogenous surface, free of any gaps, thus avoiding damage to the strip surface. Unlimited possibilities in roll coating extend the service life of the roll surface virtually indefinitely.
Thanks to the higher mill production capacity and improved strip quality ANDRITZ delivers, you can count on an even faster return on investment in most cases.

During the cold rolling process, the rolling stock warms irregularly over the strip width for various reasons. These temperature differences lead to proportional strip length modifications. In practice, a strip temperature difference of at least 20–30 kelvin occurs frequently. If this temperature effect is not considered at the time of the online shape measurement, it leads to shape differences when comparing the online shape measurement and the offline shape measurement after cooling of the strip.

As an extra option, the shape:tronic system can also be used to detect the relative strip temperature profile over the strip width and compensate for temperature effects, thus permitting shape measurement that is largely independent of the strip temperature.

Advantages of the shape:tronic system

roll diameter between 200 and 500 mm
seamless and homogenous roll surface in four (4) different designs
- hardened and ground steel
- special rubber or polyurethane
- chromium
- tungsten carbide
measuring zone widths between 15 and 60 mm
high-precision active piezo quartz with single-wire technology
maintenance-free and contactless digital data transmission
computer system with robust and integrated controller, no hard disk
shape control algorithm with MPC technology, for use in all rolling mills
easy-to-use operator interface

Griding of a shapemeter roll

With full-liner hubs in Germany, China, and the USA, ANDRITZ delivers excellent service capabilities including:
