Metris vibe - Integrative solution for condition monitoring

Wireless data communication for reading processes in machinery equipment

Metris Vibe is a wireless vibration and temperature sensor for periodically monitoring the health status of mechanical equipment, regardless of the manufacturer. It provides data via Bluetooth Low Energy (BLE) either to a mobile device or an industrial gateway that is connected to the Metris UX digitalization platform. This platform combines a complete set of functionalities for professional production management, simulation and optimization.

State-of-the art communication

Metris Vibe is available in two versions. One which is fully encapsulated and ATEX certified, and another version which has an exchangeable battery. This allows the selection of a sensor that ideally fits the environmental conditions and requirements on site.

Metris vibe communicates in real-time directly with the Metris dashboard on site and in the cloud on the Metris UX platform to make all data visible for the operator at any time.

pic_metris-vibe-workflow_nonwoven-and-textile

BENEFITS:

Enables long-term cost savings
Easy to install
First indication of machine health
Wireless connection
Tranmission of raw data
Battery life up to three years
Exchangeable battery
Interface to Metris UX App for Android and iOS devices

pic_metris-vibe-QR-codes_nonwoven-and-textile

Download Metris Vibe app from here (scan QR-code)

Common technical data:

Analysis frequency bandwidth: up to 12,800 Hz
Frequency resolution: down to 200 mHz
Measurement ranges: ±8 g, ±16 g, ±32 g
RF communication: 2.4 GHz low power, BLE
MCU: Ultra-low power consumption Arm® Cortex®
Firmware: Wireless update possible
Mounting orientation: all orientations
Mounting /system connection: M8 x 1.25 thread (magnetic and adhesive mounting possible)
Operating temperature: -40 °C to 85 °C
